Overview
The Versa Drone Electronic Speed Controller (ESC) is a high-voltage, industrial-grade motor controller for multirotor and UAV platforms. It is designed to drive high-power BLDC drone motors from a 50–61.5 V DC (up to 14S Li-ion) bus, delivering 1 kW continuous and 3 kW peak (60 s) output power.
In terms of voltage class, current capability and mechanical envelope, it has been engineered to be compatible with widely used high-voltage drone ESCs such as the Hobbywing X8, so OEMs already using that class of controller can evaluate Versa as a potential replacement after their own fit and validation checks.
Using sensorless FOC, CAN communication and standard RC PWM input, this ESC suits both OEM drone manufacturers and advanced integrators who need robust performance, protection and diagnostics beyond hobby-level controllers.
Key Features
High-voltage DC input
- 50 to 61.5 V DC input range (up to 14S Li-ion packs)
High power density
- 1000 W continuous output power
- 3000 W peak output power for 60 seconds
- 55 Arms peak output current
Advanced motor control
- 3-phase BLDC motor drive
- Sensorless FOC (Field Oriented Control) for high efficiency and smooth torque
- Maximum motor speed: 4000 RPM
Dual control interface
- CAN interface for speed command, telemetry and configuration
- Standard RC PWM input (1050 to 1950 µs pulse width) for throttle control
Configurable behaviour
- Drive address and rotation direction configurable via CAN or hard-coded options
Protections and warnings
- Warnings: DC bus under-voltage / over-voltage, over-current, over-temperature, overload
- Protections: throttle loss, locked rotor and short-circuit protection
Rugged mechanical design
- IP66-rated enclosure
- Operating temperature: -10 to 50 °C
- Compact form factor: 80 mm diameter × 30 mm height
- Weight < 1500 g
Status indication
- Dual LEDs (green & red) with defined patterns for normal, warning and fault states
Typical Applications
- Multirotor and UAV propulsion for:
- Industrial inspection and monitoring
- Agricultural spraying and mapping
- Surveying / LiDAR / photogrammetry platforms
- Heavy-lift or long-endurance multirotors
- High-voltage BLDC propeller drives where reliability and diagnostics are critical
Technical Specifications
Indicative values; integration should be validated with your motor, propeller and mission profile.
| Parameter | Value | Unit |
|---|---|---|
| Maximum working voltage | 50 to 61.5 | V DC |
| Continuous input current | 20 | A |
| Continuous output power | 1000 | W |
| Peak output power (60 s) | 3000 | W |
| Peak output current | 55 | Arms |
| Motor type | BLDC | – |
| Control method | Sensorless FOC | – |
| Maximum motor speed | 4000 | RPM |
| Controller efficiency | > 84.5 | % |
| Communication interface | CAN | – |
| Speed command | PWM (pulse width 1050 to 1950 µs) | – |
| Drive address and rotation direction | Configurable through CAN or hard-coded | – |
| User interface | Green & red LEDs with status patterns | – |
| Warnings | DC bus under-voltage, DC bus over-voltage, over-current, over-temperature, overload | – |
| Protections | Throttle loss, locked rotor, short-circuit | – |
| Weight | < 1500 | g |
| Dimensions | 80 (D) × 30 (H) | mm |
| Operating temperature | -10 to 50 | °C |
| IP rating | IP66 | – |
Enquiry Note
If you are interested, please share a few lines about your product, motor rating and supply voltage. We will review your requirement, map it to the closest Versa motor–drive platform and get back to you with next steps.
